Isuzu D - MAX

Minggu, 31 Januari 2010










Description

Isuzu DMax Single Cabin

Over the top


Spesifikasi :

Dimension & Weight
Overall Length mm 5040
Overall Width mm 1800
Overall Height mm 1720
Wheel Base mm 3050
Curb Weight kg 1795
Gross Vehicle Weight kg 2750
Clearence Height mm 210
Cargo length mm 2270
Cargo Width mm 1520
Cargo Height mm -
Seating Capacity 3

Gradebility

Angle of Approach degree 36
Angle of Depature degree 28
Angle of Side Slip degree 49
Min. Turning Radius m 6.2

Engine

Model 4JJ1
Type Turbo Intercooler
Displacement cc 2999
Max. Power Ps / Rpm 136/3400
Max. Torque Kgm/Rpm 28.5/1200-3400
Configuration -
Bore X Stroke mm 95.4 x 104.9
Compression Ratio :1 -
Camshaft DOHC
Fuel Supply System -
Fuel Tank Capacity L 76
Fuel Filler -

Drive Train

Transmission Type 5MT
4WD Std
Transfer Control Switch Control (Shift On the Fly)
Hub Lock Front Axle Disconnected
Model MUA-5H
Limited Slip Differential Std

Gear Ratio 1st 4.008
2nd 2.301
3rd 1.427
4th 1.000
5th 0.745
rev. 3.651
Final Gear Ratio 4.100

Brake & Suspension

Brake Type Front Disc
Rear Drum
Suspension Type Front Double Wishbone with torsion Bar Spring and Stabilizer
Rear Rigid Leaf - Spring
Tire & Wheels Steel 225/75R15C
Parking Brake Stick

Safety

ABS 4WD with EBD system --
SRS Airbag --
Side intrusion door beams Front Std
Rear --

Security

Power door locks --
Child lock --

Lamps

Head lamp H4 Multi Reflector (2Bulb)
Fog Lamps --
High Mount Stop Lamp --
Interior Lamp, Dome Lamp Std
Map Lamp --
Horn Single

Comfort & Convenience

Seat Arrangement Front Bench
Rear --
Head Rest Front Separate Adjustable
Rear Std
Audio Space 2 X Din-A Form Size Audio
2 Speaker stereo with Cassette Std
4 Speaker stereo with Cassette --
Air Conditioner Std
Front wiper Std
Rear Defogger --
Front Console with 2-Cup Holders
Rear Console --
Tilted Steering --

* Spesifikasi dapat berubah sesuai dengan perkembangan teknologi

Description

Isuzu DMax Double Cabin


Over the top

Spesifikasi :

Dimension & Weight

Overall Length mm 4925
Overall Width mm 1800
Overall Height mm 1720
Wheel Base mm 3050
Curb Weight kg 1880
Gross Vehicle Weight kg 2750
Clearence Height mm 210
Cargo length mm 1380
Cargo Width mm 1520
Cargo Height mm -
Seating Capacity 2+3

Gradebility

Angle of Approach degree 36
Angle of Depature degree 28
Angle of Side Slip degree 49
Min. Turning Radius m 6.2

Engine

Model 4JJ1
Type Turbo Intercooler
Displacement cc 2999
Max. Power Ps/Rpm 136/3400
Max. Torque Kgm/Rpm 28.5/1200-3400
Configuration 4 cyl., in-line
Bore X Stroke mm 95.4 x 104.9
Compression Ratio :1 -
Camshaft DOHC
Fuel Supply System Electornic Controlled
Fuel Tank Capacity 76
Fuel Filler Remote Opener

Drive Train

Transmission Type 5MT
4WD Std
Transfer Control Switch Control (Shift On the Fly)
Hub Lock Front Axle Disconnected
Model MUA-5H
Limited Slip Differential Std
Gear Ratio 1st 4.008
2nd 2.301
3rd 1.427

Description

Isuzu DMax Rodeo LS


Over the top

Spesifikasi :

Dimension & Weight

Overall Length mm 5030
Overall Width mm 1800
Overall Height mm 1735
Wheel Base mm 3050
Curb Weight kg 1880
Gross Vehicle Weight kg 2750
Clearence Height mm 225
Cargo length mm 1380
Cargo Width mm 1520
Cargo Height mm -
Seating Capacity 2+3

Gradebility

Angle of Approach degree 36
Angle of Depature degree 28
Angle of Side Slip degree 49
Min. Turning Radius m 6.2

Engine

Model 4JJ1
Type Turbo Intercooler
Displacement cc 2999
Max. Power Ps/Rpm 136/3400
Max. Torque Kgm/Rpm 28.5/1200-3400
Configuration --
Bore X Stroke mm 95.4 x 104.9
Compression Ratio :1 -
Camshaft DOHC
Fuel Supply System --
Fuel Tank Capacity 76
Fuel Filler --

Drive Train

Transmission Type 5MT
4WD Std
Transfer Control Switch Control (Shift On the Fly)
Hub Lock Front Axle Disconnected
Model MUA-5H
Limited Slip Differential Std
Gear Ratio 1st 4.008
2nd 2.301
3rd 1.427
4th 1.000
5th 0.745
rev. 3.651
Final Gear Ratio 4.300

Brake & Suspension

Brake Type Front Disc
Rear Drum
Suspension Type Front Double Wishbone with torsion Bar Spring and Stabilizer
Rear Rigid Leaf - Spring
Tire & Wheels Alloy Wheel 225/75R15C
Parking Brake Floor

Safety

ABS 4WD with EBD system Std
SRS Airbag Drive & Passenger
Side intrusion door beams Front Std
Rear Std

Security

Power door locks Std
Child lock Std

Lamps

Head lamp H4 Projector Type (4Bulb)
Fog Lamps Std
High Mount Stop Lamp Std
Interior Lamp, Dome Lamp Std
Map Lamp Std
Horn Dual

Comfort & Convenience

Seat Arrangement Front Bucket
Rear Bench-Folding Back
Head Rest Front Separate Adjustable
Rear Separate Adjustable
Audio Space 2 X Din-A Form Size Audio
2 Speaker stereo with Cassette --
4 Speaker stereo with Cassette Std
Air Conditioner Std
Front wiper with Intermittent
Rear Defogger Std
Front Console with 2-Cup Holders
Rear Console with LID
Tilted Steering Std

* Spesifikasi dapat berubah sesuai dengan perkembangan teknologi
